eMax 20 S HST
Horsepower19.4 HP
TransmissionHST
3-Point Hitch Lift Capacity680 lbs
Loader lift capacity617 lbs
Get A Quote

Save up to $1,000!

7-Year Limited Powertrain Warranty*

eMax 25L HST Cab
Horsepower24 HP
TransmissionHST
3-Point Hitch Lift Capacity1323 lbs
Loader lift capacity 900 lbs
Get A Quote

Save up to $1,250!

7-Year Limited Powertrain Warranty*

Offers

Top Features

Implements

Get your work done with Mahindra implements that are perfect to handle any job you need to tackle.

Attachments

Built tough and built to last like our Tractors, Mahindra attachments handle the toughest tasks to keep working smarter; not harder.

Specs

Tractor ModeleMax 20S HSTeMax 20S HST CabeMax 25L HST Cab
Engine TypeFour-stroke, Naturally Aspirated, Indirect Injection, Water-cooled Diesel Engine, Complies with US TIER-4 Final NormsFour-stroke, Naturally Aspirated, Indirect Injection, Water-cooled Diesel Engine, Complies with US TIER-4 Final Norms Four-stroke, Naturally Aspirated, Indirect Injection, Water-cooled Diesel Engine, Complies with US TIER-4 Final Norms
Engine HP [kW] @ RPM19.4 (14.5) @ 300019.4 (14.5) @ 300024 (18) @ 2600
Displacement [in3 (cc)]60.6 (993)60.6 (993)71.7 (1175)
Number of Cylinders333
Fuel Tank [gal (L)]6.6 (25)6.6 (25)5.8 (22)

Tractor ModeleMax 20S HSTeMax 20S HST CabeMax 25L HST Cab
TransmissionHST – 2 rangesHST – 2 rangesHST – 2 ranges
Number of SpeedsInfiniteInfiniteInfinite
ClutchDry-SingleDry-SingleDry-Single
BrakesWet DiscWet DiscWet Disc

Tractor ModeleMax 20S HSTeMax 20S HST CabeMax 25L HST Cab
PTO TypeIndependentIndependentIndependent
Rear PTO RPM540 @ 2942540 @ 2942540 @ 2550
Mid PTO RPM2500 @ 29582500 @ 29582500 @ 2550
PTO HP (kW)14.2 (10.6)14.2 (10.6)16.9 (12.26)

Tractor ModeleMax 20S HSTeMax 20S HST CabeMax 25L HST Cab
TypeOpen CenterOpen CenterOpen Center
Implement Pump Output [gpm (L/min)]4.1 (15.5)4.1 (15.5)4.5 (17.0)
Maximum Total Flow [gpm (L/min)]6.2 (23.4)6.2 (23.4)7.1 (26.9)
3-Point HitchCAT I Narrow with Check ChainsCAT I Narrow with Check ChainsCAT I with Check Chains
Loader Lift Capacity [lb (kg)]617 (280)617 (280)1323 (600)

Tractor ModeleMax 20S HSTeMax 20S HST CabeMax 25L HST Cab
Battery12 V, 450 CCA12 V, 450 CCA12 V, 450 CCA
Alternator12 V, 45 A12 V, 45 A12 V, 50 A

Tractor ModeleMax 20S HSTeMax 20S HST CabeMax 25L HST Cab
Overall Length [in (mm)]94.2 (2392)94.2 (2392)100.5 (2552)
Overall Width [in (mm)]44.5 (1130) 44.5 (1130)45.8 (1164)
Overall Height [in (mm)]86.6 (2299) 79.6 (2023)78.2 (1986)
Wheelbase [in (mm)]53.1 (1348) 53.1 (1348)57.5 (1460)
Minimum Ground Clearance [in (mm)]8.3 (210) 8.3 (210)9.4 (240)
Turning Radius [ft (m)]7.2 (2.1)7.2 (2.1)7.2 (2.1)
Weight [lb (kg)]1499 (679.9) 1800 (817) 1870 (850)

Tractor ModeleMax 20S HSTeMax 20S HST CabeMax 25L HST Cab
AG [Front/Rear]18 x 8.5-10 / 26 x 12-1218 x 8.5-10 / 26 x 12-126 x 12 / 9.5 x 16
IND [Front/Rear]18 x 8.5-10 / 26 x 12-1218 x 8.5-10 / 26 x 12-1220 x 18-10 / 27 x 12.5-15
TURF [Front/Rear]18 x 8.5-10 / 26 x 12-1218 x 8.5-10 / 26 x 12-1220 x 8-10 / 29 x 12.5-15
