2123 HST
Horsepower 23 HP
Transmission HST – 3 Range
3-Point Hitch Lift Capacity 1760 lbs
Loader lift capacity 1477 lbs
Get A Quote Virtual Demo

Save up to $1,000!

2126 HST
Horsepower 25.3 HP
Transmission HST – 3 Range
3-Point Hitch Lift Capacity 1760 lbs
Loader lift capacity 1477 lbs
Get A Quote Virtual Demo

Save up to $1,000!

Offers

Top Features

Implements

With value-packed features, Mahindra implements are built to be as tough as our tractors. We overbuild them for years of uninterrupted performance so you can focus on transforming your property into the land you love!

Attachments

Like our tractors, Mahindra attachments are engineered to tackle the most demanding jobs. They add versatility, too. No need for a separate backhoe or a riding mower. We have every solution to meet your unique needs, all in one tractor.

Specs

Tractor Model2123 HST2126 HST2126 HST Cab
Engine typeNaturally Aspirated, Indirect Injection, Water Cooled DieselNaturally Aspirated, Indirect Injection, Water Cooled DieselNaturally Aspirated, Indirect Injection, Water Cooled Diesel
Engine HP [kW] @ RPM22.9 (17.1) @ 250025.3 (18.9) @ 270025.3 (18.9) @ 2700
Displacement [in3 (cc)]80.4 (1318)80.4 (1318)80.4 (1318)
Number of cylinders333
Fuel tank [Gal (L)]5.8 (22)5.8 (22)5.8 (22)
Bore & stroke [in]Bore : 3.1, Stroke: 3.6Bore : 3.1, Stroke: 3.6Bore : 3.1, Stroke: 3.6

Tractor Model2123 HST2126 HST2126 HST Cab
Transmission typeHST – 3 rangeHST – 3 rangeHST – 3 range
Number of speedsInfiniteInfiniteInfinite
ClutchN/AN/AN/A
Max speed (mph)11.211.211.2
BrakesDual pedalDual pedalDual pedal

Tractor Model2123 HST2126 HST2126 HST Cab
PTO typeIndependentIndependentIndependent
Rear PTO RPM540540540
Mid PTO RPM2500 @ 25002500 @ 25002500 @ 2500
PTO HP (kW)16.8 (12.5)18.8 (14.0)18.8 (14.0)

Tractor Model2123 HST2126 HST2126 HST Cab
TypeOpen center with Position ControlOpen center with Position ControlOpen center with Position Control
Maximum total flow [GPM (L/min)]11.211.211.2
Total pump output, main (GPM)6.36.36.3
Total pump output, steering (GPM)555
3-Point hitchCat ICat ICat I
3- Point hitch lift capacity @24" aft [lb (kg)]176017601760

Tractor Model2123 HST2126 HST2126 HST Cab
Battery630 CCA, 52 AH630 CCA, 52 AH630 CCA, 52 AH
Alternator55 A55 A55 A

Tractor Model2123 HST2126 HST2126 HST Cab
Overall length [in (mm)]112.7 (2863)112.7 (2863)112.7 (2863)
Wheelbase [in (mm)]61.4 (1560)61.4 (1560)61.4 (1560)
Turning radius [ft (m)]7.6 (2.3)7.6 (2.3)7.6 (2.3)
Overall width [in (mm)]54.4 (1383)54.4 (1383)54.4 (1383)
Overall height [in (mm)]95.5 (2426)95.5 (2426)87.5 (2223)
Minimum ground clearance [in (mm)]13.4 (340)13.4 (340)13.4 (340)
Weight [lb (kg)]210121012607

Tractor Model2123 HST2126 HST2126 HST Cab
IND [Front/Rear]8.5×14 / 12.4-168.5×14/12.4-168.5×14 / 12.4-16
TURF [Front/Rear]8.5×14 / 13.5-168.5×14/ 13.5-168.5×14 / 13.5-16

Tractor Model2123 HST2126 HST2126 HST Cab
Model numberL21L21L21
Max lift height (in)82.4482.4482.44
Loader lift capacity [lb (kg)]1389 (630)1389 (630)1389 (630)
Digging depth (in)3.143.143.14
